| ITEM | A | B | C | D | E | WLL (LBS) | WT (LBS) |
|---|---|---|---|---|---|---|---|
| T6DQKL-18 | 1/8” | 1-3/16” | 1-15/32” | 3/16” | 1/2” | 330 | 0.02 |
| T6DQKL-316 | 3/16” | 1-9/16” | 1-7/8” | 1/4” | 5/8” | 720 | 0.05 |
| T6DQKL-14 | 1/4” | 1-5/8” | 2-1/4” | 9/32” | 3/4” | 990 | 0.08 |
| T6DQKL-516 | 5/16” | 2-1/4” | 2-1/2” | 3/8” | 1” | 1,400 | 0.2 |
| T6DQKL-38 | 3/8” | 2-5/8” | 3-7/16” | 9/16” | 1-3/16” | 2,100 | 0.3 |
| T6DQKL-1532 | 15/32“ | 3” | 4-1/8” | 9/16” | 1-5/16” | 3,200 | 0.52 |
